Engine Go kart
- Brand: Indian Brand
₹110,000 – ₹195,000
150 cc kids kart – Honda gx 160 engine , dry clutch
200 cc kids kart – Honda gx 200 engine , dry clutch
160 cc beginner kart – Honda gx 160 engine , dry clutch
200 cc beginner kart – Honda gx 200 engine , wet clutch
200 cc intermediate kart – Honda gx 200 engine , wet clutch
200 cc superadvance kart – Honda gx 200 engine , wet clutch
200 cc full covered kart – Honda gx 200 engine , wet clutch
200 cc twin seater kart – Honda gx 270 engine , wet clutch
270 cc twin seater kart – Honda gx 270 engine , wet clutch
200 cc mud kart – Honda gx 200 engine , wet clutch
200 cc twin mud kart – Honda gx 200 engine , wet clutch
270 cc twin mud kart – Honda gx 270 engine , wet clutch
Details |
Electric Go- kart |
|
Seating capacity |
1Nos/2 Nos |
|
Pay |
300kgs |
|
Turning radius |
1800 mm |
|
Ground clearance |
50 mm |
|
Overall |
180 |
|
Tyres |
10×4.5-5 Front 11×7.1-5 Rear |
|
Rims |
Standard rim |
|
Motor |
3/5 |
|
Controller |
Kelly /Curtis programmable |
|
Electrical system |
48 V |
|
Battery |
48V 45Ah Li-Ion |
|
Charger |
Turbo |
|
Steering |
Ackerman |
|
Transmission |
Timing |
|
Paint |
PU Metallic/ PU ( As per clients requirement ) |
|
Brakes |
Hydraulic |
|
Frame |
Powder coated steel chassis |
|
Body |
Fiber panel |
|
Speed |
65 km/hr |
|
Safety |
4 point / 2 point auto retractable seat belts |
|
Grade |
15 |
|
Guardrail |
UV Protected Virgin HDPE |
|
Range |
90 Minutes |
|
Battery display Indicator |
Curtis |
Sr.No. |
Parameters |
Petrol Go kart |
Electric go kart |
1 |
Power |
Engine 200 cc /270 cc/390 cc |
Motor 3 to 6 KW |
2 |
Brand of drive unit |
Engine brand- Honda Generator |
BLDC UK brand motor , 48 V 50 AH LFP with smart BMS |
3 |
Cost of drive unit |
Engine cost Rs.19500 incl gst for 200 cc |
Motor-35 Turbo Charger -25k |
4 |
Controller |
Controller –NA |
Controller –Kelly programmable |
5 |
Electric start |
Electric start optional |
NA |
6 |
Transmission |
Chain and shaft drive |
Timing Belt and pulley |
7 |
Rear |
Self-aligning bearing |
Self-aligning bearing |
8 |
Fuel Indicator |
NA |
Curtis BDI |
9 |
Panels |
Fibreglass |
Fibreglass |
10 |
Chassis Tubing |
32 / 25 /20 mm |
30 / 25 /20 mm |
11 |
Welding process |
TIG Welding |
TIG Welding |
12 |
Seats |
Optional Adjustable |
Optional Adjustable |
13 |
Braking |
Four piston caliper hydraulic braking |
Four piston caliper hydraulic braking |
14 |
Steering wheel |
Momo Italy |
Momo Italy |
15 |
Bearings |
SKF/HKS |
SKF/HKS |
16 |
DRL |
With self-start kit |
Available |
17 |
Emergency |
By default |
By default |
18 |
Seat belts |
Optional |
Optional |
19 |
Reverse |
NA |
Optional |
20 |
Side |
Virgin HDPE Sheet |
Virgin HDPE Sheet |
21 |
Fasteners |
SS fasteners and MS |
SS fasteners and MS |
22 |
Chassis |
Powder coat |
Powder coat |
23 |
Front bearing |
Taper bearing |
Taper bearing |
24 |
Nuts |
Locknuts |
Locknuts |
25 |
Gearbox |
Wet clutch gearbox |
NA |
26 |
Back up |
25 |
90 min /Charge |
27 |
Battery |
NA |
LFP with Smart BMS LG /Samsung/CATL ( 3 yrs Warranty ) |
28 |
Type of fuel |
Petrol |
Electric charging |
Sr.No. |
Parameters |
Petrol Go kart |
Electric go kart |
1 |
Tyre change |
Every after 100 kms Approximately |
Every after 100 kms Approximately |
2 |
Greecing |
By default |
By default |
3 |
Oiling |
Every after 1 month |
Every after 1 month |
4 |
Gearbox maintenance |
Clutch and pressure plates |
NA |
5 |
Battery charging |
NA |
Every after 90 min |
6 |
Drive power change cost |
Engine Rs.19500 |
Motor-35 Turbo Charger -25k |
7 |
Drive setting |
Engine setting |
Programming |
8 |
Refueling |
Instant |
Need back up battery and 1 hr charging time |
9 |
Local maintenance |
Possible |
Possible with trained technician |
10 |
AMC |
Available |
Available |
